Knife Gate Valve

Features of Knife Gate Valve

• Full bore design for high media throughput capacity;

• U-shaped gasket with good sealing effect;

• Gate plate with gate function, good shut-off effect, can effectively shut off all kinds of debris in the media, to solve the leakage phenomenon after shut-off containing lumps, particles and fiber media;

• Able to work in dirty media, easy to install, easy to disassemble, easy to maintain, without removing the valve can replace the valve seals, making valve maintenance more simple.

Knife Gate Valve Working Principle

The wiper between the valve body and bonnet of the knife gate valve prevents solid particles from entering the bonnet. The valve body cavity, seat configuration and slant gate design provide features to impede the entry of thick media (e.g. pulp, slurry) or solid media (e.g. granules and powders).   銆�銆�

Knife gate valve gate and seat are always in close contact with the sealed valve, the gate with a guide hole with the same through conduit gate valve, the gate has a through diameter size of the round hole, through the gate opening and closing so that the round hole on the gate and the through diameter to do a complete disengagement and coincide with the action. In addition, the advantage of the structure is that the valve body diameter without grooves, the medium will not be blocked, and has a full diameter flow characteristics, suitable for the use of powder and particle media in the pipeline. Its sealing structure can be divided into soft seal, hard seal structure. Sealed valve seat is designed with movable structure, with anti-wear and automatic compensation function, thus longer life. In the process of closing and opening the valve seat and the gate plate have been close to the movement, so that the valve opening and closing force is stable.

Knife Gate Valve Installation and Commissioning

Knife gate valve can be divided into pneumatic knife gate valve, electric knife gate valve, manual knife gate valve. According to the operation mode, Installation and operation according to the different operating instructions. For specific use, please consult Zeco Valve Group.

Knife Gate Valve Material and Standard

Size Range: 2"~48"
Pressure Rating: 10bar ~ 20bar

Face to Face Dimensions: MSS SP-81-2006

Flange End Dimension: EN1092, ASME B16.5, ASME B16.47, AS2129

Inspection and Test: MSS SP-81-2006
